ABI BA 2200
Updated: 16.10.2023
| ABI BA 2200 | |
|---|---|
| Torque | 2,200 daNm |
| Revolutions | 50 min⁻1 |
| Static extraction force max. | 200 kN |
| Hydraulic flow rate | 220 l/min |
| Required oil quantity per rotation | 4,4 l |
| Hydraulic power at auger drive max. | 60 kW |
| Nominal oil pressure | 32 MPa |
| Total weight | 600 kg |
| Transport weight | 700 kg |
| Hexagon connection | 80 mm |
| Height H1 | 1,390 mm |
| Width B | 710 mm |
| Depth T | 540 mm |
| Transport dimensions: | |
| Height | 1,565 mm |
| Width | 9,000 mm |
| Depth | 710 mm |
